Brass CNC Machining
Services On Aria
Brass has excellent ductility, excellent flexibility and high feed compatibility – making it the first choice for manufacturers seeking fast, cost-effective production without compromising quality.
Upload 3D CAD File to Start A New CNC Machining Quote
What is Brass CNC Machining?
Brass CNC machining is a precision manufacturing process that uses computer-controlled (CNC) machines to cut, shape, and finish brass parts with high accuracy. Brass—an alloy of copper and zinc—is favored for its excellent machinability, corrosion resistance, and electrical conductivity.
CNC machining ensures tight tolerances (as precise as ±0.005mm) and repeatability, making it ideal for industries like electronics, automotive, plumbing, and decorative hardware.
Why Choose Brass CNC Machining?
Excellent Machinability
Softer than steel, brass cuts easily, reducing tool wear and production time.
Corrosion Resistance
Perfect for marine, plumbing, and outdoor applications.
Electrical & Thermal Conductivity
Widely used in electrical connectors and heat exchangers.
Aesthetic Appeal
Polished brass provides a premium, decorative finish.
Types of Brass Materials
Brass Subtypes
Tensile Strength, Yield (MPa)
Fatigue Strength (MPa)
Elongation at Break (%)
Hardness (Brinell)
Density (g/cm³)
Brass C260
95
90
65
54
8.53
Brass C360
124 - 310
138
53
63 - 130
8.49
Brass C274
150 - 280
110
50 - 60
55 - 80
8.47
Brass C280
255 - 345
115
40 - 50
40 - 50
8.53
Brass CNC Machining Parameter
Parameter
Turning
Milling
Drilling
Threading
Spindle Speed (RPM)
800–2,500
1,500–4,000
3,000–6,000
500–1,500
Spindle Power (kW)
3–15
5–20
2–10
2–8
Feed Rate (mm/min)
100–400
200–800
50–200
50–150
Cutting Depth (mm)
0.5–3.0
0.2–2.0
–
–
Cutting Width (mm)
–
0.5–4.0 (radial)
–
–
Machining Accuracy
±0.01–0.05mm
±0.02–0.1mm
±0.05–0.2mm
±0.02–0.05mm
Surface Roughness
Ra 0.8 - 3.2 μm
0.4–1.6μm
1.6–6.3μm
0.8–3.2μm
Tool Type
Carbide insert
Carbide end mill
HSS/Carbide drill
HSS/Carbide tap
Tool Diameter
6–25
3–20
1–20
M2–M20
Coolant Type
Emulsion/Mist
Emulsion/Mist
Emulsion/Mist
Tapping fluid
